Series

67.0 Symmetrical Control Valve

  • 67.0 Symmetrical Control Valve
67.0 Symmetrical Control Valve

Series

67.0 Symmetrical Control Valve

Article number
67050-JA52-AAT1
1 × 10-8 mbar to 1.2 bar (abs)

Flow optimized pressure control

  • Technical data
  • Downloads
Size
DN 320 (12")
Flange
JIS
Material
Aluminum
Actuator
Stepper motor
Controller interface + sensors
Logic (A/D) / 2 sensors
Controller configuration
SPS and PFO
Position indication signal
No
Solenoid
No
Pressure min.
1 × 10-8 mbar
Pressure max.
1.2 bar (abs)
Conductance
0.25 ls⁻¹
Differential pressure on plate
≤ 1 bar
Differential pressure at opening
≤ 1 bar
Close to open
typ. 2.0 s
Open to close
typ. 2.0 s
Pressure control (throttling) default speed
typ. 1.0 s per 100 mm
Max. compressed air pressure
7 bar / 102 psi
Min. compressed air pressure
4 bar / 58 psi
Weight
31 kg / 68 lbs
Max. temperature valve body
≤ 120 °C
Add-Ons for Your Product
Valve
Controller-Interface
Gate
Temperature Management

67.0 Symmetrical Control Valve 67050-JA52-AAT1 3D CAD File

ZIP 1.49 MB

67.0 Symmetrical Control Valve 67050-JA52-AAT1 2D Dimension Drawing

PDF 552.33 KB

67.0 Symmetrical Control Valve 67050-JA52-AAT1 Product Datasheet

PDF 37.58 KB

Spare parts

Please specify your spare part need at the end of your selection process, on the next page.
