Series

65.3 HV Pendulum Control Valve

  • 65.3 - 65348-PAHE
65.3 - 65348-PAHE

Series

65.3 HV Pendulum Control Valve

Article number
65348-PAHE
1 × 10-8 mbar to 1.2 bar (abs)

Optimized Downstream Pressure Control & Vacuum Isolation in SEMI & Display Systems

  • Technical data
  • Downloads
Size
DN 250 (10")
Flange
ISO-F
Material
Aluminum
Actuator
Stepper motor
Controller interface + sensors
Logic (A/D) / 2 sensors
Controller Configuration
PFO
Position Indication Signal
No
Solenoid
No
Pressure Min.
1 × 10-8 mbar
Pressure Max.
1.2 bar (abs)
Conductance
22000 ls⁻¹
Differential Pressure on Plate
≤ 1 bar
Differential Pressure at opening
≤ 1 bar
Close to open
4 s
Open to close
3 s
Pressure control (throttling) fast speed
0.5 s
Pressure control (throttling) default speed
0.9 s
Max. compressed air pressure
7 bar / 102 psi
Min. compressed air pressure
4 bar / 58 psi
Weight
29 kg / 64 lbs
Max. temperature valve body
≤ 120 °C
Add-Ons for Your Product
Valve
Temperature Management
Actuator
Gate

65.3 HV Pendulum Control Valve 65348-PAHE Product Datasheet

PDF 254.95 KB

65.3 HV Pendulum Control Valve 65348-PAHE 3D CAD File

ZIP 679.17 KB

65.3 HV Pendulum Control Valve 65348-PAHE 2D Dimension Drawing

PDF 845.13 KB

Spare parts

Please specify your spare part need at the end of your selection process, on the next page.
